ARTEC 3D Scanners

ARTEC, based in Luxembourg, manufacture a range of 3D scanners which are world leaders in high accuracy 3D scanners.

Applications for ARTEC 3D scanners includes:

  • Industrial design
  • Manufacturing
  • Health care
  • Movie & gaming industry
  • Heritage preservation
  • Museums
  • Education

SURVEY SOLUTIONS can supply GEOMAGIC software with ARTEC 3D scanners which provides a perfect solution for all engineering and industrial design applications. GEOMAGIC produce the following software options:

  • GEOMAGIC for SOLIDWORKS
  • GEOMAGIC WRAP
  • GEOMAGIC CONTROL
  • GEOMAGIC DESIGN X

SURVEY SOLUTIONS is a certified trainer for ARTEC 3D scanners.

A range of case studies on applications for ARTEC 3D scanners is available here.

3D models available for viewing on website

ARTEC RAY

This is an ultra high precision tripod based 3D laser scanner with the following features:

  • Accuracy 0.7mm @ 15m range
  • Range up to 110 meters
  • Colour
  • Range noise 0.12mm @ 15m range
  • Process in ARTEC STUDIO software

For further details please watch the following video on ARTEC RAY click here

ARTEC Micro

The ARTEC Micro is an ultra high precision desktop metrology grade 3D scanner with the following features:

  • Accuracy up to 10 microns (0.01mm)
  • Resolution up to 29 microns (0.029mm)
  • Full colour & texture
  • Texture resolution 6.4 mp
  • Ideal for small machine parts, jewelry and dentistry

Further details available here

ARTEC LEO

The ARTEC LEO 3D Scanner is a smart professional full colour handheld 3D scanner works outdoors in bright sunlight and indoors and is ideal for a huge range of applications and is ARTEC's best all round 3D scanner with the following features:

  • 3D scanning speeds of up to 44x 3D frames per second
  • Integrated computer NVIDIA Tegra
  • 9 DoF inertial system for accelerometer, gyro & compass
  • Built in rechargeable battery
  • Capture expansive areas and fine detail from small engineering parts to large boats or vehicles
  • Accuracy up to 100 microns (0.1mm)
  • Resolution 500 microns (0.5mm)
  • Maximum field of view 843mm x 527mm
  • Working range 0.35 - 1.2 meters
  • Works outdoors in bright sunlight

Watch the following video of the LEO in action outdoors and indoors click here

Further details available here

ARTEC SPACE SPIDER

The ARTEC SPACE SPIDER is a full colour handheld 3D scanner available from ARTEC. Its ideal for reverse engineering, manufacturing and quality control with the following features:

  • Accuracy up to 50 microns (0.05mm)
  • Resolution up to 100 microns (0.1mm)
  • Full colour & texture
  • Easily captures sharp edges, holes or black surfaces
  • Portable and light weight at less than 1 kg
  • Easy to operate

Further details available here
